MTWB Solid Lubricated Tapered Roller Bearings are designed for applications where conventional grease lubrication is difficult, unreliable or requires frequent maintenance. By integrating solid lubrication technology into tapered roller bearing structures, these bearings provide stable friction performance, extended service intervals and reliable operation under harsh working conditions.
Designed with advanced polymer matrix embedded solid lubricant technology, this tapered roller bearing delivers reliable self-lubricating performance under high loads, low speeds, high temperatures, dusty environments, and heavy industrial operating conditions. MTWB helps OEM manufacturers improve equipment reliability while reducing maintenance costs and extending service life through application-specific bearing solutions.
| Item | Specification |
|---|---|
| Bearing Type | Tapered Roller Bearing |
| Lubrication Type | Solid Lubrication |
| Bearing Structure | Cone, Cup, Tapered Rollers and Cage |
| Load Capability | High Radial and Axial Load |
| Friction Performance | Low Friction Operation |
| Maintenance | Reduced Maintenance Requirement |
| Temperature Resistance | Customized According to Application |
| Precision Grade | P6 / P5 Customized |
| Cage Material | Steel / Customized |
| Application | Heavy Machinery, Industrial Equipment |
The solid lubrication mechanism is based on a proprietary polymer material injected into the bearing through a specialized process. This polymer material adsorbs saturated lubricating oil, ensuring that the lubricant remains tightly and continuously in contact with the raceways and rollers, effectively preventing contaminants from entering the bearing interior.
The lubricating oil is “stored” in the micro-pores within the polymer based on surface tension. During operation, a small portion of the lubricating oil slowly moves to the material surface due to capillary action; when operation stops, the lubricating oil re-adheres to the polymer for “storage”.This unique circulation mechanism ensures consistent lubrication throughout the bearing service life.
| Lubricant Model | Food Grade | Ultimate Temperature | Injection Molding Process Limit Speed | Viscosity of Base Oil | Color |
|---|---|---|---|---|---|
| E mould | – | 150℃ | 3000 RPM | Custom made | White |
| G mould | – | 155℃ | 3000 RPM | Custom made | Black |
| Type F2 | – | 155℃ | 4500 RPM | Custom made | Red |
| Technical Grade F2 | – | 150℃ | 4500 RPM | Custom made | Red |
| Type F1 | – | 200℃ | 1000 RPM | Custom made | Black |
| D mould | – | 150℃ | 3000 RPM | Custom made | Blue |
| C mould | – | 120℃ | 5000 RPM | Custom made | Yellow |
| B mould | – | 120℃ | 3000 RPM | Custom made | Green |
| A mould | – | 120℃ | – | Custom made | – |
Note: Lubricating oil (grease) content ranges from 40% to 95%
As a customized bearing manufacturer, MTWB offers tailored Solid Lubrication TRB solutions to meet specific application requirements.
Key customizable parameters include:
Bearing dimensions (inner diameter, outer diameter, width) – tailored to your equipment specifications
Load capacity – optimized for radial and axial load requirements
Solid lubricant type – selection from multiple polymer formulations based on operating temperature, speed, and environmental conditions
Lubricant content – adjustable from 40% to 95% based on application needs
Sealing design – integrated sealing for enhanced contamination protection
Speed rating – customizable with limit speeds ranging from 1,000 RPM to 5,000 RPM depending on lubricant type
With polymer matrix adsorption saturated lubricant technology, a lubricant seamlessly adheres to the raceway and rolling elements without the need for an external oil supply system – re-greasing is completely eliminated.
Solid lubricant content is 2–4 times higher than traditional lubricants, extending bearing service life by more than 3 times and significantly reducing the frequency of spare parts replacement.
The solid lubricant remains in close contact with the raceway and rollers, almost filling the entire bearing. The remaining space within the body effectively prevents pollutants from entering, protecting the bearing from contamination-related failures.
Lubricating oil is stored in the micropores inside the polymer. During operation, oil is transferred to the material surface under capillary action; when operation stops, oil is reabsorbed into the polymer for “storage” – eliminating environmental pollution caused by lubricating oil leakage.
Suitable for ambient temperatures up to 200℃, as well as high humidity, dust, and chemical corrosion environments.The solid lubrication bearing retains oil within the bearing and features an integral bearing seal to further improve oil retention.
Solid lubricants support integral seals and provide very good anti-rinsing ability, making them ideal for washdown and high-moisture environments.
Ideal for applications where lubricant contamination is a critical concern, including food processing and clean manufacturing environments.
Mining equipment
Construction machinery
Agricultural machinery
Heavy trucks
Industrial gearboxes
Steel processing equipment
Furnace equipment
Material handling systems
Answer:A solid lubricated tapered roller bearing uses solid lubrication materials instead of conventional grease to reduce friction and provide reliable performance in difficult lubrication environments.
Answer:Solid lubrication bearings offer longer maintenance intervals, stable lubrication performance and improved reliability under high temperature, vacuum or contaminated environments.
Answer:Yes. MTWB provides customized tapered roller bearing solutions including dimensions, lubrication type, clearance, precision grade and application-specific designs.
Answer:MTWB can develop customized replacement solutions according to original bearing dimensions and application requirements.
Contact MTWB today to discuss your related solid lubrication TRB tapered roller bearing requirements and receive a professional bearing solution. Click here to know MTWB whole solid lubrication bearing solution.
MTWB (Mighty Way Industrial Limited) is a professional sold lubrication trb tapered roller bearings manufacturer and OEM bearing supplier specializing in high precision miniature bearings and application-specific bearing solutions.
With advanced manufacturing capabilities, comprehensive testing systems, and engineering expertise, MTWB helps global customers develop reliable bearing solutions for demanding applications.
